Hinge Covers
Dell™Latitude™E6410/E6410ATGServiceManual
Removing the Hinge Covers
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove the ATG Port Cover (applicable on E6410 ATG computer only).
3. Remove the battery.
4. Remove the screws that secure the hinge covers to the computer.
5. Slide the hinge covers toward the back of the computer and remove the hinge cover.
Replacing the Hinge Covers
To replace the hinge covers, perform the above steps in reverse order.
Back to Removing and Replacing Parts
WARNING: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
NOTE: You may need to install Adobe®Flash®Player from Adobe.com in order to view the illustrations below.
