Dell Latitude E6410 - Processor Removal and Replacement

Back to Removing and Replacing Parts
Processor
Dell™Latitude™E6410/E6410ATGServiceManual
Removing the Processor
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove the ATG Port Cover (applicable on E6410 ATG computer only).
3. Remove the battery.
4. Remove the access panel.
5. Remove the Heat Sink and Processor fan.
6. Rotate processor cam lock counter clock-wise.
7. Lift the processor and remove it from the computer.
Replacing the Processor
To replace the processor, perform the above steps in reverse order.
Back to Removing and Replacing Parts
WARNING: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
NOTE: You may need to install Adobe®Flash®Player from Adobe.com in order to view the illustrations below.
