Dell Latitude E6410 - WWAN Card Removal and Replacement

Back to Removing and Replacing Parts
WWAN Card
Dell™Latitude™E6410/E6410ATGServiceManual
Removing the WWAN Card
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove the ATG Port Cover (applicable on E6410 ATG computer only).
3. Remove the battery.
4. Remove the access panel.
5. Disconnect any antenna cables that may be connected to the WWAN card.
6. Remove the screw that secures the WWAN card in the computer.
7. Remove the WWAN card from the computer.
Replacing the WWAN Card
To replace the WWAN card, perform the above steps in reverse order.
Back to Removing and Replacing Parts
WARNING: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
NOTE: You may need to install Adobe®Flash®Player from Adobe.com in order to view the illustrations below.
