Dell Latitude E6410 - Access Panel Removal and Replacement

Back to Contents Page
Access Panel
Dell™Latitude™E6410/E6410ATGServiceManual
Removing the Access Panel
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove the ATG Port Cover (applicable on E6410 ATG computer only).
3. Remove the battery.
4. Loosen the captive screw that secures the access panel to the base of the computer.
5. Slide the access panel toward the front of the computer.
6. Lift and remove the access panel off of the computer.
Replacing the Access Panel
To replace the access panel, perform the above steps in reverse order.
Back to Removing and Replacing Parts
WARNING: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
NOTE: You may need to install Adobe®Flash®Player from Adobe.com in order to view the illustrations below.
