Visão geral do hardware
237
Figura 2. LEDs das portas
LED de empilhamento
Azul contínuo - Switch
no modo de
empilhamento mestre
Verde contínuo -
Comutador no modo de
empilhamento
secundário
Desligado - Comutador
no modo independente
No painel traseiro
LED localizador
Azul piscante - Função
localizadora ativada
Azul contínuo - Função
localizadora desativada
No painel traseiro
a. O limite de temperatura do sistema de sensores térmicos é de 75ºC. Quando este limite é
ultrapassado, o LED da temperatura se torna vermelho.
Tabela 1. Definições de LED para o sistema (Continua)
Recurso Descrição detalhada Comentário
9
10
11
12
15
16
1
2
17
18
13
14
7
8
5
6
PowerConnect 8164
1
2
1
2
1
2
1
2
9
10
11
12
23
24
15
16
21
22
2319
20
17
18
13
14
7
8
5
6
3
4
Console
Locator
FAN 1
Temp
Dlag
Stack
OOB
LED do sistema
