Page #39 background imageLoading...
Page #39 background image
硬件概览
37
系统
LED
系统包含提供有关
Dell Networking N4000
交换机的系统、温度、断、
风扇、堆栈和定位状态示的发光二极
(LED)
1
包含状态
LED
定义
1.
系统的
LED
定义
功能 详细说明 注释
系统
LED
稳定蓝色
-
正常运行
闪烁蓝色
-
正在引导
稳定红色
-
严重系统
错误
闪烁红色
-
非严重系统
错误(风扇故障、电源
设备故障)
在前面板上
温度
LED
熄灭
-
正常温度
稳定红色
-
温度过高
a
a. 热感器系统温度阈值为 75°C。超出阈值时,温度 LED 灯呈红色亮起。
在背面板上
诊断
LED
熄灭
-
正常运行
闪烁绿色
-
正在运行诊
断测试
在背面板上
风扇
LED
稳定绿色
-
风扇电源打
开且处于预期
RPM
稳定红色
-
风扇出现
故障
在背面板上
堆栈
LED
稳定蓝色
-
切换至堆栈
主模式
稳定绿色
-
切换至堆栈
从模式
熄灭
-
切换至独立模式
在背面板上
定位器
LED
闪烁蓝色
-
定位器功能
启用
稳定蓝色
-
定位器功能
禁用
在背面板上
