Dell Networking S4048 - S4048-ON Configurations

• Mounting brackets for rack installation, included
• Screws for rack installation
• #1 and #2 Phillips screwdrivers, not included
• Torx screwdriver, not included
• Ground cable screws, included
• Copper/ber cables
Other optional components are:
• Ground cable
• Additional power supply unit
• Additional fan module
• Additional mounting brackets if installing in a four-post rack or cabinet
S4048–ON congurations
You can order the S4048–ON system in several dierent congurations. You can also order optional modules and optics separately.
You can order the following supported hardware components:
• S4048–ON AC Normal Airow: 48 port 10 G RJ-45 ports with six QSFP+ 40 G ports, one AC power supply and three fan subsystems.
Airow is from the I/O-side to the PSU-side.
• S4048–ON AC Reverse Airow: 48 port 10 G RJ-45 ports with six QSFP+ 40 G ports, one AC power supply and three fan subsystems.
Airow is from the PSU-side to the I/O-side
• Fan with airow from the I/O-side to the PSU-side
• Fan with airow from the PSU-side to the I/O-side
• AC Power supply with airow from the I/O-side to the PSU-side
• AC Power supply with airow from the PSU-side to the I/O-side
The S4048–ON system
