Dell Networking S4048 - System Status; LED Display

System status
You can view S4048–ON status information using the light emitting diodes (LEDs).
LED display
The S4048–ON includes LED displays on both the I/O Port and PSU side of the chassis, as shown.
For LED information, see your third-party operating software documentation.
Figure 4. S4048–ON LEDs
1 SFP+ port Link and activity LEDs
2 System LEDs
3 QSFP+ port LEDs
4 FAN LED
5 Management port LEDs
6 PSU LED
