Dell NX3230 - Page 14

Item Indicator, button, or
connector
Icon Description
If the system stops responding during POST, press
and hold the system ID button for more than five
seconds to enter BIOS progress mode.
To reset iDRAC (if not disabled in F2 iDRAC setup)
press and hold the button for more than 15
seconds.
2 System identification
connector
Connects the optional system status indicator
assembly through the optional cable management
arm.
3 iDRAC8 Enterprise port Dedicated management port.
4 Half-height PCIe
expansion-card slot (3)
Allows you to connect up to three half-height PCI
Express expansion cards.
5 Serial connector Allows you to connect a serial device to the
system.
6 Video connector Allows you to connect a VGA display to the system.
7 USB connector (2) Allows you to connect USB drives to the system.
The ports are USB 3.0-compliant.
8 Full-height PCIe
expansion-card slot (3)
Allows you to connect up to three full-height PCI
Express expansion cards.
9 Ethernet connector (4) Four integrated 10/100/1000 Mbps NIC
connectors
or
Four integrated connectors that include:
• Two 10/100/1000 Mbps NIC connectors
• Two 100 Mbps/1 Gbps/10 Gbps SFP+/10 GbE T
connectors
10 Power supply unit (PSU1)
AC 750 W, or 1100 W
or
DC 750 W or 1100 W
11 Power supply unit
(PSU2)
12 vFlash media card slot Allows you to insert a vFlash media card.
13 HDD (2) (back) Up to two hot-swappable 2.5-inch HDDs.
