Steps
1. Place the tabs on the right side of the hard-drive caddy onto the holders on the chassis and push the left side of the caddy
down until it clicks into place.
NOTE: Use the arrows seen on the caddy as guides to identify the tabs on the tray.
2. Connect the hard-drive data and power cables to the connectors on the hard drive.
Next steps
1. Install the side cover.
2. Follow the procedure in after working inside your computer.
M.2 solid-state drive
Removing the M.2 2230 PCIe solid-state drive
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the side cover.
3. Remove the front bezel.
4. Remove the 3.5/2.5-inch hard-drive assembly.
5. Remove the hard-drive and optical-drive bracket.
24
Removing and installing components
