Dell OptiPlex 3090 Small Form Factor User Manual

Power-supply unit
Removing the power-supply unit
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the side cover.
3. Remove the 3.5/2.5-inch hard-drive assembly.
4. Remove the hard-drive and optical-drive bracket.
About this task
The following images indicate the location of the power-supply unit and provide a visual representation of the removal
procedure.
Removing and installing components 47
