Steps
1. Align the notch on the memory module with the tab on the memory-module slot.
2. Slide the memory module firmly into the slot at an angle and press the memory module down until it clicks into place.
NOTE: If you do not hear the click, remove the memory module and reinstall it.
Next steps
1. Install the hard-drive and optical-drive bracket.
2. Install the 3.5/2.5-inch hard-drive assembly.
3. Install the side cover.
4. Follow the procedure in after working inside your computer.
Processor
Removing the processor
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the side cover.
3. Remove the heat-sink and fan assembly.
4. Remove the 3.5/2.5-inch hard-drive assembly.
5. Remove the hard-drive and optical-drive bracket.
About this task
The following images indicate the location of the processor and provide a visual representation of the removal procedure.
44
Removing and installing components
