Installing cover
1 Place the cover on the computer and slide the cover forward until it clicks into place.
2 Follow the procedure in After working inside your computer.
Front Bezel
Removing the front bezel
1 Follow the procedure in Before working inside your computer.
2 Remove the cover.
3 To remove front bezel:
a Lift the tabs to release the bezel from the chassis [1].
b Remove the front bezel from the computer [2].
NOTE
: Please ensure that the tabs at the bottom of the bezel is also released before lifting the bezel.
Disassembly and reassembly 11
