Dell OptiPlex 5055 Small Form Factor User Manual

Installing front bezel
1 Insert the tabs of the bezel into the slots on the chassis.
2 Press the bezel until the tabs click into place.
3 Install the cover.
4 Follow the procedure in After working inside your computer.
Storage device
Removing 2.5–inch hard drive assembly
1 Follow the procedure in Before working inside your computer.
2 Remove the cover.
3 To remove the 2.5-inch drive assembly:
a Disconnect the SATA cable and power cable from the drive [1].
b Push the tab to release drive assembly from the chassis [2].
12
Disassembly and reassembly
