Table 1. Screw list (continued)
Component Screw type Quantity Image
Processor fan and 65 W heat-sink assembly #6-32 (Captive) 4
VR heat sink #6-32 (Captive) 2
System board #6-32
M2x4
9
1
Major components of your system
1. Side cover
2. 3.5-inch hard-drive assembly
3. Optical Disk Drive
Removing and installing components
11
