Dell OptiPlex 7090 Tower - Page 78

Steps
1. Remove the (#6-32) screw that secures the front I/O-bracket to the chassis.
2. Slide and remove the front I/O-bracket from the chassis.
3. Disconnect the power cables that are connected to the system board and unroute them from the routing guides on the
chassis.
78
Removing and installing components
