34 Optical Drive
Replacing the Optical Drive
1
Follow the instructions in "Before You Begin" on page 9.
2
Slide the optical drive into the optical-drive bay until it is fully seated.
3
Replace the screw that secures the optical drive to the base cover.
4
Replace the module cover (see "Replacing the Module Cover" on page 16).
5
Replace the battery (see "Replacing the Battery" on page 14).
CAUTION: Before turning on the computer, replace all screws and ensure that no
stray screws remain inside the computer. Failure to do so may result in damage to
the computer.
1 screw 2 optical drive
3 base cover
book.book Page 34 Wednesday, April 25, 2012 2:11 PM
