60 Display
Replacing the Display Bezel
1
Follow the instructions in "Before You Begin" on page 9.
2
Align the display bezel with the display back cover, and gently snap it into
place.
3
Replace the display assembly (see "Replacing the Display Assembly" on
page 58).
CAUTION: Before turning on the computer, replace all screws and ensure that no
stray screws remain inside the computer. Failure to do so may result in damage to
the computer.
Display Panel
Removing the Display Panel
1
Follow the instructions in "Before You Begin" on page 9.
2
Remove the display assembly (see "Removing the Display Assembly" on
page 55).
3
Remove the display bezel (see "Removing the Display Bezel" on page 59).
4
Remove the camera module (see "Removing the Camera Module" on
page 77).
NOTE: The touch-screen board is optional and may not be present in your
computer.
5
Remove the touch-screen board, if applicable:
a
Pull the pull-tab to disconnect the touch-screen board cable from the
connector on the touch-screen board.
book.book Page 60 Wednesday, April 25, 2012 2:11 PM
