Dell P09E002 - Replacing the Display-Panel Brackets

Display 67
Replacing the Display-Panel Brackets
1 Follow the instructions in "Before You Begin" on page 9.
2 Place the display-panel brackets in position.
3 Replace the eight screws (four on each side) that secure the display-panel
brackets to the display panel.
4 Replace the display panel (see "Replacing the Display Panel" on page 63).
5 Replace the camera module (see "Replacing the Camera Module" on
page 80).
6 Replace the display bezel (see "Replacing the Display Bezel" on page 60).
7 Replace the display assembly ("Replacing the Display Assembly" on
page 58).
1 display panel brackets (2) 2 screws (8)
1
2
