Display 69
Replacing the Display Hinges
1
Follow the instructions in "Before You Begin" on page 9.
2
Place the display hinges in position.
3
Replace the four screws (two on each side) that secure the display hinges
to the display back cover.
4
Replace the display panel (see "Replacing the Display Panel" on page 63).
5
Replace the camera module (see "Replacing the Camera Module" on
page 80).
6
Replace the display bezel (see "Replacing the Display Bezel" on page 60).
7
Replace the display assembly ("Replacing the Display Assembly" on
page 58).
1 display back cover 2 screws (4)
