44 Keyboard
7
Turn the keyboard over and place it on the top cover.
8
Lift the connector latch and pull the pull-tab to disconnect the keyboard
backlight cable from the system-board connector.
9
Lift the connector latch and pull the pull-tab to disconnect the keyboard
cable from the system-board connector.
1 keyboard 2 tabs (6)
3 top cover
book.book Page 44 Wednesday, April 25, 2012 2:11 PM
