62 Display
NOTE: The IR emitter board is optional and may not be present in your computer.
6 Remove the IR emitter board, if applicable:
a Pull the pull-tab to disconnect the IR emitter board cable from the
connector on the IR emitter board.
1 screws (8) 2 hinges (2)
3 display panel
1
2
3
