Setting up the monitor │ 61
Using DPBS function
Waking on the USB-C cable
When you connect the USB-C cable, the Monitor/PC state is as follows:
Initial monitor power state (No cable)
USB-C
Initial system power state (ON)
New power state of system (ON)
Connect USB-C cable
USB-C
New power state of monitor (ON)
USB-C
1 2
Initial monitor power state (No cable)
USB-C
Initial system power state (OFF)
New power state of system (ON)*
Connect USB-C cable
USB-C
New power state of monitor (ON)*
USB-C
1 2
* Not all Dell PC systems support to wake up the platform
via the monitor.
* After connect the USB-C cable, tap on Keyboard or
moving the mouse for the system to continue its boot
up process when necessary.
