Installing microSD card
1. Slide the SD card into its slot until it clicks into place.
2. Install the microSD card.
3. Follow the procedure in After working inside your computer.
Base cover
Removing base cover
1. Follow the procedure in Before working inside your computer.
2. Remove the microSD card.
3. To remove the base cover:
a. Remove the mylar cap [1].
NOTE: The screw cover on the base cover is made up of a mylar sticker. To remove this screw, use a regular philips
driver and puncture the mylar cover. Once the mylar caps are removed it cannot replaced, and the screws will be
exposed from that point forward.
b. Loosen the M2.5x7 captive screws that secure the base cover to the computer [2] .
c. Pry the base cover from the edge.
NOTE: You may need a 3c plastic scribe to pry the base cover from the edge.
4. Lift the base cover away from the computer.
8
Disassembly and reassembly
