152 시작 안내서
www.dell.com | support.dell.com
그림 3. 콘솔 포트에 연결
콘솔 포트 아래의 RJ-45 포트는 대역외 관리용입니다.
스위치 부팅
1 스위치 콘솔 포트가 RS-45 DB9 케이블을 통해 VT100 터미널 또는 VT100 터미널
에뮬레이터에 연결되어 있는지 확인합니다.
2 AC 전원 개를 습니다.
3 AC 전원 콘센트를 성화합니다.
4 스위치 전원 공급 장치를 모두 AC 연결합니다.
5 AC 전원 성화합니다.
터미널을 연결한 에서 전원을 스위치에서 POST(Power-In Self-Test) 수행됩
니다. POST 스위치가 시작될 때마 실행되어 완료되기 전에 하드웨어 구성요소
사하여 스위치가 작동 가능한지 여부를 확인합니다. POST에서 중요한 제가 발견
프로그 흐름이 중지됩니다. POST 통과하면 펌웨어가 RAM 로드됩니다
.
POST 시지가 터미널에 표시되어 스트 성공 여부를 려줍니다. 프로세스는
60 소요됩니다.
콘솔 포트
