Installing System Components 111
NOTE: If you are upgrading your system to a 16
–
hard-drive configuration, turn
off the system and remove all the chassis blanks. To remove the chassis blank,
press down and push the blue release tab toward the front of the system. See
Figure 3-13.
3
Press the button on the front of the drive carrier and open the handle.
4
Insert the hard-drive carrier into the drive bay until the carrier contacts
the backplane.
5
Close the handle to lock the drive in place.
Figure 3-13. Removing a Chassis Blank
1 chassis blank 2 release tab
book.book Page 111 Wednesday, January 20, 2010 10:20 AM
