Installing System Components 107
Installing the Memory-Riser Guide
1
Align the memory-riser guide with the slots on the chassis.
2
Lower the memory-riser guide into the system until the tabs click
into place.
3
Install the memory risers. See "Installing a Memory Riser" on page 101.
4
If applicable, install the memory-riser blanks. See "Installing a Memory-
Riser Blank" on page 100.
5
Close the system. See "Closing the System" on page 90.
6
Reconnect the system and peripherals to their power sources, and turn
them on.
Hard Drives
All drives connect to the system board through the SAS/SATA backplane
board. Hard drives are supplied in special hot-swappable drive carriers that fit
in the hard-drive bays.
CAUTION: Before attempting to remove or install a drive while the system is
running, see the documentation for the SAS controller card to ensure that the host
adapter is configured correctly to support hot-swap drive removal and insertion.
CAUTION: Do not turn off or reboot your system while the drive is being formatted.
Doing so can cause a drive failure.
NOTE: Use only drives that have been tested and approved for use with the
SAS/SATA backplane board.
When you format a hard drive, allow enough time for the formatting to be
completed. Be aware that high-capacity hard drives can take a number of
hours to format.
