14 About Your System
LCD Panel Features
The system's LCD panel provides system information and status and error
messages to signify when the system is operating correctly or when the system
needs attention. See "LCD Status Messages" on page 23 for information
about specific status codes.
The LCD backlight lights blue during normal operating conditions and lights
amber to indicate an error condition. When the system is in standby mode,
the LCD backlight is off and can be turned on by pressing either the Select,
Left or Right button on the LCD panel. The LCD backlight will remain off if
LCD messaging is turned off through the iDRAC utility, the LCD panel, or
other tools.
9 System identification
panel
A slide-out panel for system information
including the Express Service tag,
embedded NIC MAC address, and
iDRAC6 Enterprise card MAC address.
Space is provided for an additional label.
10 Hard drives Up to sixteen 2.5-inch, external
hot-swappable SAS or SSD hard drives.
NOTE: Only one SATA drive is supported
on the x4 backplane. SAS and SATA hard
disks on the same backplane cannot be
combined into a single virtual disk. x16
backplanes do not support SATA drives.
Item Indicator, Button, or
Connector
Icon Description
book.book Page 14 Wednesday, January 20, 2010 10:20 AM
