Dell PowerEdge E06S Series - SAS Backplane Board Connectors

200 Jumpers and Connectors
SAS Backplane Board Connectors
Figure 6-2. x16 SAS Backplane Board Connector
22 J_CPU1 Processor 1
23 MEM_RISER_A Memory riser A connector
24 MEM_RISER_B Memory riser B connector
25 MEM_RISER_E Memory riser E connector
26 MEM_RISER_F Memory riser F connector
27 MEM_RISER_C Memory riser C connector
28 MEM_RISER_D Memory riser D connector
29 MEM_RISER_G Memory riser G connector
30 BP_PWR/MISC Power connector
31 MEM_RISER_H Memory riser H connector
32 SATA_PWR SATA power connector
Table 6-2. System Board Jumpers and Connectors
Item Connector Description
1
4
5
2
3
6
book.book Page 200 Wednesday, January 20, 2010 10:20 AM
