172 Installing Blade Components
Figure 3-13. Memory Locations PowerEdge M915
D8
D4
D7
D3
D6
D2
D5
D1
C1
C5
C2
C6
C3
C7
C4
C8
CPU2
CPU1
B1
B5
B2
B6
B3
B7
B4
B8
A8
A4
A7
A3
A6
A2
A5
A1
CPU3
CPU4
