354 System Board Information
PowerEdge M610x Mezzanine Interface Card
Figure 7-11. PowerEdge M610x Mezzanine Interface Card Connectors
3 PCIe 2 Expansion-card connector 2
4 PCIe 1 Expansion-card connector 1
5 Data 3 Data cable connector 3
6 Data 4 Data cable connector 4
7 - Riser-card power connector
Connector Description
1
2
3
