270 Installing Blade Components
Installing a Hard Drive in a Hard-Drive Carrier
1 Insert the hard drive into the hard-drive carrier with the drive’s
controller board’s connector end of the drive at the back of the carrier.
See Figure 3-57.
2
From the back of the carrier, slide the drive into the carrier until it contacts
the stop tab on the front of the carrier.
3 Align the screw holes on the hard drive with the holes on the hard-drive
carrier. For SATA drives, align the drive mounting holes with the carrier
mounting holes marked SATA. See Figure 3-57.
CAUTION: To avoid damaging the drive or the carrier, do not overtighten the
screws.
4 Attach the four screws to secure the hard drive to the hard-drive carrier.
