Dell PowerEdge M620 - CMC Module

Installing Enclosure Components 293
CMC Module
Removing a CMC Module
1 Disconnect the cables attached to the CMC module.
2 Push the release latch on the handle and rotate the handle away from the
module front panel.
3 Slide the CMC module out of the enclosure.
4 Install the I/O connector cover. See Figure 4-4.
Figure 4-4. Removing and Installing a CMC Module or iKVM Module (CMC Module
Shown)
1 I/O connector cover 2 release latch
3 release lever
2
1
3
