Dell PowerEdge M620 User Manual

18 About Your System
LCD Module
The LCD module provides an initial configuration/deployment wizard, as
well as easy access to infrastructure and blade information, and error
reporting. See Figure 1-5.
Figure 1-5. LCD Display
1 LCD screen 2 selection ("check") button
3 scroll buttons (4)
1
3
2

Dell PowerEdge M620 Specifications

General

Memory	Up to 768GB (24 DIMM slots): 2GB/4GB/8GB/16GB/32GB DDR3 up to 1866MT/s
Management	iDRAC7 with Lifecycle Controller
Processor Options	Intel Xeon processor E5-2600 and E5-2600 v2 product families
Storage	Up to two 2.5" hot-plug SAS, SATA or SSD drives
RAID Controller	PERC H310, H710, H710P
Operating System Support	Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware vSphere
