192 Installing Blade Components
8 GB Four 2 GB
UDIMMs
A2, A3, B2, B3 Two Advanced
ECC
8 GB
8 GB Four 2 GB
UDIMMs
A2, A3, A5, A6 One Mirroring 4 Gb
8 GB Four 2 GB
UDIMMs
A2, A3, A5, A6 One Advanced
ECC
8 Gb
12 GB Six 2 GB
UDIMMs
A1, A2, A3, A4,
A5, A6
One Independent
channel
12 GB
12 GB Six 2 GB
UDIMMs
A1, A2, A3, B1,
B2, B3
Two Independent
channel
12 GB
16 GB Eight 2 GB
UDIMMs
A2, A3, A5, A6,
B2, B3, B5, B6
Two Mirroring 8 GB
16 GB Eight 2 GB
UDIMMs
A2, A3, A5, A6,
B2, B3, B5, B6
Two Advanced
ECC
16 GB
24 GB Twelve 2 GB
RDIMMs
A2, A3, A5, A6,
A8, A9, B2, B3,
B5, B6, B8, B9
One Advanced
ECC
24 GB
24 GB Six 4 GB
UDIMMs
A1, A2, A3, A4,
A5, A6
One Independent
channel
24 GB
24 GB Six 4 GB
RDIMMs
A1, A2, A3, B1,
B2, B3
Two Independent
channel
24 GB
32 GB Eight 4 GB
RDIMMs
A2, A3, A5, A6,
B2, B3, B5, B6
Two Mirroring 16 GB
32 GB Eight 4 GB
RDIMMs
A2, A3, A5, A6,
B2, B3, B5, B6
Two Advanced
ECC
32 GB
36 GB Nine 4 GB
RDIMMs
A1, A2, A3, A4,
A5, A6, A7, A8,
A9
One Independent
channel
36 GB
64 GB Eight 8 GB
RDIMMs
A2, A3, A5, A6,
B2, B3, B5, B6
Two Mirroring 32 GB
Table 3-8. Examples of PowerEdge M710 Memory Configurations
(continued)
Total
Physical
Memory
Memory Modules
– Number and
Type
Memory Module
Locations
Processors Memory
Mode
Available
Memory
