Installing Blade Components 209
Table 3-13. Memory Sparing Configurations – PowerEdge M605
Processor 1 Processor 2
Available
Memory
Spared
Memory
DIMM
1
DIMM
2
DIMM
3
DIMM
4
DIMM
5
DIMM
6
DIMM
7
DIMM
8
1 CPU /
2CPUs
1 CPU /
2 CPUs
512
MB
512
MB
512
MB*
512
MB*
512
MB
512
MB
512
MB*
512
MB*
1 GB / 2
GB
1 GB / 2
GB
1 GB* 1 GB* 512
MB
512
MB
1 GB* 1 GB* 512
MB
512
MB
1 GB / 2
GB
2 GB / 4
GB
1 GB 1 GB 1 GB* 1 GB* 1 GB 1 GB 1 GB* 1 GB* 2 GB / 4
GB
2 GB / 4
GB
2 GB* 2 GB* 512
MB
512
MB
2 GB* 2 GB* 512
MB
512
MB
3 GB / 6
GB
2 GB / 4
GB
2 GB 2 GB 1 GB* 1 GB* 2 GB 2 GB 1 GB* 1 GB* 4 GB / 8
GB
2 GB / 4
GB
2 GB 2 GB 2 GB* 2 GB* 2 GB 2 GB 2 GB* 2 GB* 6 GB / 12
GB
2 GB / 4
GB
4 GB* 4 GB* 512
MB
512
MB
4 GB* 4 GB* 512
MB
512
MB
5 GB / 10
GB
4 GB / 8
GB
4 GB* 4 GB* 1 GB 1 GB 4 GB* 4 GB* 1 GB 1 GB 6 GB / 12
GB
4 GB / 8
GB
4 GB* 4 GB* 2 GB 2 GB 4 GB* 4 GB* 2 GB 2 GB 8 GB / 16
GB
4 GB / 8
GB
4 GB 4 GB 4 GB* 4 GB* 4 GB 4 GB 4 GB* 4 GB* 12 GB / 24
GB
4 GB / 8
GB
* Indicates a spared single-rank DIMM (512 MB or 1 GB). The entire capacity of this DIMM is
reserved for sparing.
Indicates a spared dual-rank DIMM (2 GB and higher). One-half of this DIMM’s capacity is
reserved for sparing.
