230 Installing Blade Components
Figure 3-32. Removing or Installing the RAID Battery (PowerEdge M610/M610x Only)
1 RAID battery cable 2 RAID battery
3 tabs (3) 4 metal standoffs (3)
5 storage controller card
1
2
4
5
3
