Installing Blade Components
245
Figure 3-40.
Installing and Removi
ng the Heat Sink (PowerEdge M915)
1h
e
a
t
s
i
n
k
NOTE:
Y
ou must install the heat sink in
the orientation shown here.
2
screws (4)
3
processor 4
4
processor 2
5
processor 3
6
processor 1
6
5
1
2
3
4
244
246
