System Board Information 343
8 C1 – C4 Memory modules C1 – C4
9PSWD_EN,
NVRAM_CLR
System configuration jumpers
NOTE: Access requires removal of system board. See
"Removing the System Board" on page 276.
10 - Connector for the 3.0 V coin battery
NOTE: Access requires removal of system board. See
"Removing the System Board" on page 276.
11 J_STORAGE Storage controller card connector
12 - Hard-drive backplane connector
13 - Hardware key socket for integrated NIC TOE/iSCSI
feature
14 CPU3 Processor 3 socket
15 CPU1 Processor 1 socket
16 A1 – A8 Memory modules A1 – A8
17 - Video controller card connector
18 MEZZ1_FAB_C Mezzanine card connector 1 Fabric C
19 MEZZ2_FAB_B Mezzanine card connector 2 Fabric B
20 MEZZ3_FAB_C Mezzanine card connector 3 Fabric C
Table 7-11. PowerEdge M905 System Board Connectors
(continued)
Connector Description
