356 System Board Information
8 CPU2 Processor 2 socket
9 TOE_KEY Hardware key socket for enabling the integrated NIC
TOE/iSCSI feature
10 PWRD_EN,
NVRAM_CLR
Configuration jumpers
11 SASBKPLN Hard-drive backplane connector
12 BATTERY Connector for the 3.0 V coin battery
13 J_STORAGE Storage controller card connector
14 B1 Memory module connector, slot B1
15 B2 Memory module connector, slot B2
16 B3 Memory module connector, slot B3
17 B4 Memory module connector, slot B4
18 J_VIDEO Video controller card connector
Table 7-18. PowerEdge M605 System Board Connectors
(continued)
Connector Description
To Next Page
