Figure 1-28. Dell M8428-k 10 Gb Converged Network Switch
1 LED status indicators (12) 2 serial port (RJ-45 connector)
3 module status indicator 4 diagnostic status indicator
5 power indicator 6 8 Gb Fibre Channel ports
(ports 25–27 and port 0)
7 10 GbEE ports (ports 17–24)
7
1
2
3
4
5
6
