84 About Your System
Figure 1-35. PowerConnect M6220 Ethernet Switch Module Features
1 optional module (2) (dual 10 Gb
Ethernet uplink module shown)
2 standard 10/100/1000 Mb Ethernet
connectors (4)
3 serial connector (USB type-A form
factor)
4 status/identification indicator
5 power indicator
