Figure 1-42. Brocade M4424 SAN I/O Module Features
1 Fibre Channel port (8) 2 Fibre Channel port status
indicator (8)
3 Fibre Channel port speed
indicator (8)
4 serial port (RJ-45 connector)
5 module status indicator 6 status/identification indicator
7 power indicator
