Dell PowerEdge R860 User Manual

Figure 156. Installing a power supply unit adapter
Next steps
1. Follow the procedure listed in After working inside your system.
Removing a power supply unit
Prerequisites
CAUTION:
The system requires one power supply unit (PSU) for normal operation. On power-redundant
systems, remove and replace only one PSU at a time in a system that is powered on.
1. Follow the safety guidelines listed in the Safety instructions.
2. Disconnect the power cable from the power outlet and from the PSU that you intend to remove.
3. Remove the cable from the strap on the PSU handle.
4. Unlatch and lift or remove the optional cable management accessory if it interferes with the PSU removal.
NOTE:
For information about the cable management when the PSU is removed or installed while the system is in a rack,
see the system’s cable management arm documentation at https://www.dell.com/poweredgemanuals.
Steps
Press the release latch and holding the PSU handle, slide the PSU out of the bay.
Installing and removing system components
183

Dell PowerEdge R860 Specifications

General

Form Factor	2U Rack
Memory Slots	32 DIMM slots
Network Options	1GbE
Power Supplies	Redundant power supplies
Operating System Support	Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi
