2. Lower the air shroud into the system until it is firmly seated.
Figure 34. Installing the air shroud
Next steps
1. Follow the procedure listed in After working inside your system.
Drives
Removing a drive blank
Prerequisites
1. Follow the safety guidelines listed in the Safety instructions.
2. If installed, remove the front bezel.
CAUTION: To maintain proper system cooling, drive blanks must be installed in all empty drive slots.
Steps
Press the release button, and slide the drive blank out of the drive slot.
78
Installing and removing system components

Dell PowerEdge R860 Specifications

General

Form Factor	2U Rack
Memory Slots	32 DIMM slots
Network Options	1GbE
Power Supplies	Redundant power supplies
Operating System Support	Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi
