Installing System Components 121
7
Place the system upright and on its feet on a flat, stable surface.
8
Rotate the system feet outward.
9
Reattach any peripherals, then connect the system to the electrical outlet.
10
Turn on the system and attached peripherals.
Removing the Internal SD Module
WARNING: Only trained service technicians are authorized to remove the system
cover and access any of the components inside the system. Before you begin this
procedure, review the safety instructions that came with the system.
1
Turn off the system, including any attached peripherals, and disconnect
the system from the electrical outlet.
2
Rotate the system feet inward and lay the system on a flat surface.
3
Open the system. See "Opening the System" on page 85.
4
Disconnect the internal SD module cable from the module and from the
system board.
5
Lift upwards on the latch securing the internal SD module to the chassis,
then lift the module out of the chassis. See Figure 3-18.
6
Close the system. See "Closing the System" on page 86.
7
Place the system upright and on its feet on a flat, stable surface.
8
Rotate the system feet outward.
9
Reattach any peripherals, then connect the system to the electrical outlet.
10
Turn on the system and attached peripherals.
book.book Page 121 Monday, June 15, 2009 11:33 AM
