Dell PowerEdge T710 - Power Distribution Board (Service-Only Procedure)

156 Installing System Components
15 Rotate the system feet outward.
16 Replace the front bezel. See "Installing the Front Bezel" on page 85.
17 Reattach any peripherals and connect the system to an electrical outlet.
18 Turn on the system and attached peripherals.
Power Distribution Board (Service-Only
Procedure)
Removing the Power Distribution Board
WARNING: Only trained service technicians are authorized to remove the system
cover and access any of the components inside the system. Before you begin this
procedure, review the safety instructions that came with the system.
1 Turn off the system, including any attached peripherals, and disconnect
the system from the electrical outlet and peripherals.
2 Remove the power supplies. See "Removing a Power Supply" on page 82.
3 Rotate the system feet inward and lay the system on a flat surface.
4 Open the system. See "Opening the System" on page 85.
5 Remove the system board. See "Removing the System Board" on page 152.
6 To remove the power distribution board:
a Remove the two screws securing the power distribution board plate.
b Slide the power distribution board plate towards the front on the
system and lift it out.
c Remove all the cable connectors from the power board.
d Remove the five screws securing the power distribution board to the
plate and lift out the power distribution board.
