Installing System Components 157
Figure 3-31. Removing and Installing the Power Distribution Board
1 power distribution board plate 2 power distribution plate screws (2)
3 power distribution board 4 power distribution board cables (6)
5 securing tabs 6 power distribution board screws (5)
1
2
3
4
6
5
book.book Page 157 Monday, June 15, 2009 11:33 AM
