Installing System Components 91
1 Remove the front bezel. See "Removing the Front Bezel
" on page 84.
2
From the RAID management software, prepare the drive for removal.
Wait
until the hard-drive indicators on the hard-drive carrier signal that the
drive can be removed safely.
See your controller documentation for
information about hot-swap drive removal.
If the drive has been online, the green
activity/
fault indicator will flash as
the drive is powered down. When the drive indicators are off, the drive is
ready for removal.
3 Press the button on the front of the drive carrier and open the drive
carrier release handle to release the drive. See
Figure 3-7
.
4
Slide the hard drive out until it is free of the drive bay.
5
Insert a drive blank in the vacated drive bay. See
"Installing a Hard-Drive
Blank
" on page 90
.
CAUTION: To maintain proper system cooling, all empty hard-drive bays must
have drive blanks installed.
6
Install the front bezel. See
"Removing the Front Bezel
" on page 84.
Installing a Hot-Swap Hard Drive
CAUTION: When installing a hard drive, ensure that the adjacent drives are fully
installed. Inserting a hard-drive carrier and attempting to lock its handle next to a
partially installed carrier can damage the partially installed carrier's shield spring
and make it unusable.
CAUTION: Ensure that your operating system supports hot-swap drive
installation. See the documentation supplied with your operating system.
1 Remove the front bezel. See "Removing the Front Bezel
" on page 84.
2
If a drive blank is present in the bay, remove it. See
"Installing a Hard-
Drive Blank
" on page 90.
