Installing System Components 129
Chassis Intrusion Switch
Removing the Chassis Intrusion Switch
WARNING: Only trained service technicians are authorized to remove the system
cover and access any of the components inside the system. Before you begin this
procedure, review the safety instructions that came with the system.
1
Turn off the system and attached peripherals, and disconnect the system
from the electrical outlet and peripherals.
2
Rotate the system feet inward and lay the system on a flat surface.
3
Open the system. See "Opening the System" on page 85.
4
Disconnect the chassis intrusion switch cable from the connector on the
system board. See Figure 3-22
5
Slide the chassis intrusion switch out of the securing bracket notch.
book.book Page 129 Monday, June 15, 2009 11:33 AM
